FUJIFILM Dimatix STARFIRE SG1024/LA2Ci Industrial Printhead
FUJIFILM Dimatix STARFIRE SG1024/LA2Ci Industrial Printhead
STARFIRE SG1024/LA2Ci industrial printhead with 1,024 jets, two-color 200 dpi, 64.96 mm print width and 80 / 200 pL drop sizes.
The FUJIFILM Dimatix STARFIRE SG1024/LA2Ci is a robust, repairable drop-on-demand printhead for high-speed scanning and single-pass industrial systems. It combines a metal nozzle plate with REDIJET ink recirculation and integrated temperature control.
Key Features
1,024 individually addressable jets
64.96 mm effective print width
REDIJET continuous ink recirculation
Robust and repairable industrial construction
Technical Specifications
| Series | STARFIRE SG1024 A-Series |
|---|---|
| Addressable jets | 1,024 |
| Print width | 64.96 mm (2.55 in) |
| Native resolution | 200 dpi in two-color configuration |
| Native / largest drop size | 80 / 200 pL |
| Firing frequency | 20 / 8 kHz |
| Compatible fluids | UV-curable, organic solvent and aqueous inks |
| Nozzle plate | Metal |
| Temperature control | Yes |
Typical Applications
Two-color textile, wide-format graphics, commercial printing and industrial decoration.
Compatibility and Ordering
Compatibility depends on the printer, ink formulation, waveform, cables, electronics and operating conditions. Please send the exact printer model and current printhead part number before ordering. Installation and calibration should be completed by a qualified technician.
Download the product specification PDF
Contact Originalhead for compatibility confirmation, availability and quotation.
StarFire SG1024LA2Ci Industrial Printhead
1024 independent nozzles, 400DPI native resolution
VersaDrop variable droplet 6-20pl, smooth color gradation
